Dimensions For Custom Neodymium Magnets​

Last Updated on

January 9th, 2023 11:46 am

The strongest magnets – neodymium magnets – have various shapes and dimensions. Generally, we can divide them into blocks, discs, rings, arcs, bread shapes, and other shapes.
So, what are the dimensions that Osenc can offer, as a custom neodymium magnet supplier? What are the maximum sizes, minimum sizes, and tolerances?
We will explain this in detail below.

Note:
We will provide dimensions in 2 measuring units – Metric units and Imperial units.
However, the imperial units are for easy understanding, so you may not need to convert.
In any case, Osenc takes the metric units as confirmation.

1. Block Neodymium Magnets

1). Available sizes for block neodymium magnets

  • Length: 1 – 200mm (1/16 – 7 7/8 inches)
  • Width: 0.5 – 100mm (1/64 – 3 15/16 inches)
  • Height: 0.3 – 120mm (1/64 – 4 ¾ inches)

2). The largest block neodymium magnets

  • Rectangle: Length 200 × width 80 × height 50mm (7 7/8 x 3 1/8 x 1 15/16 inches)
  • Square: Length 100 × width 100 × height 60mm (3 15/16 x 3 15/16 x 2 3/8 inches)
  • The longest magnetization direction: 200mm (7 7/8 inches)

Note:

  • If the size of one direction is the largest, then the size of other directions should be smaller.
  • If the sizes of two directions are larger, the thickness should not be too small.

3). The smallest size of block magnets

  • Length 1 × width 1 × height 0.3mm (1/16 x 1/16 x 1/64 inches)

2. Disc Neodymium Magnets

1). Available sizes for disc neodymium magnets

  • Diameter: 1 – 120 mm (1/16 – 4 ¾ inches)
  • Height: 0.3 – 120 mm (1/64 – 4 ¾ inches)

2). The largest disc neodymium magnets

  • Diameter 120 × height 60mm (4 ¾ x 2 3/8 inches)
  • Diameter 80 × height 120mm (3 1/8 x 4 ¾ inches)

3). The smallest disc neodymium magnets

  • Diameter 1 × 0.3mm (1/16 x 1/64 inch)

Note:

  • The thickness should not be too small if the disc magnets have a large outer diameter.
  • Otherwise, the magnets are more likely to break during assembly.

3. Ring Neodymium Magnets

1). Available sizes for ring neodymium magnets

  • Outer diameters: 1.5 – 120 mm (1/16 – 4 ¾ inches)
  • Inner diameters: 0.4 – 80 mm (1/64 – 3 1/8 inches)
  • Height: 0.3 – 120 mm (1/64 – 4 ¾ inches)

2). The largest ring neodymium magnets

  • Outer diameter 120mm – inner diameter 80mm × height 60mm (4 ¾ – 3 1/8 x 2 3/8 inches)
  • Outer diameter 80mm – inner diameter 50mm × height 120mm (3 1/8 – 1 15/16 x 4 ¾ inches)

3). The smallest ring neodymium magnets

  • Outer diameter 1.5mm – inner diameter 0.4mm × height 0.3mm (1/16 – 1/64 x 1/64 inches)

Note:

  • The thickness should not be too small for ring shapes with large outer diameters.
  • The wall should not be too thin for larger ring shapes either, which are easy to break.

4. Arc Neodymium Magnets

1). Available sizes for arc neodymium magnets

  • Width: 3 – 200 mm (1/8 – 7 7/8 inches)
  • Thickness: 1.5 – 100 mm (1/16 – 3 15/16 inches)
  • Length: 1 – 200 mm (3/64 – 7 7/8 inches)

2). The biggest arc neodymium magnets

  • Width 200 × height 80 × length 50mm (7 7/8 x 3 5/32 x 1 31/32 inches)
  • Width 80 × height 50 × length 200mm (3 5/32 x 1 31/32 x 7 7/8 inches)

Note:

  • For large arc shapes, any one size should not be too thin.

3). The smallest arc neodymium magnets

  • Width 3 × height 2 × length 0.5mm (1/8 x 5/64 x 1/64 inch)

5. Bread-Shaped Neodymium Magnets

1). Available sizes for bread-shaped neodymium magnets

  • Width: 3 – 200 mm (1/8 – 7 7/8 inches)
  • Thickness: 1.5 – 100 mm (1/16 – 3 15/16 inches)
  • Length: 1 – 200 mm (3/64 – 7 7/8 inches)

2). The biggest bread-shaped neodymium magnets

  • Width 200 × height 80 × length 50 mm (7 7/8 x 3 5/32 x 1 31/32 inches)
  • Width 80 × height 50 × length 200 mm (3 5/32 x 1 31/32 x 7 7/8 inches)

Note:

  • For large bread shapes, any one size cannot be too thin.

3). The smallest bread-shaped neodymium magnets

  • Width 3 × height 2 × length 0.5mm (1/8 x 5/64 x 1/64 inch)

6. Available Sizes Of Other Custom Neodymium Magnets

Osenc is a custom neodymium magnet supplier, and we have intensive experience with magnets of big and tiny sizes. Send us an email if you are not sure what sizes are available. We will double-check and give you a free quote.
